SPN 1067 FMI 7

SPN 1067 FMI 7: Brake switch not calibrated

Quick Answer

When SPN 1067 FMI 7 sets, the ECM is indicating a fault condition involving the component or system named in the code.

OEM definitions and thresholds can vary, so confirm the exact meaning with service information or a capable diagnostic tool.

Code
SPN 1067 FMI 7
Severity
Info
Applies to
Check OEM application
Can I drive?
The immediate driving effect of SPN 1067 FMI 7 depends on whether the fault is active, the component involved, and any companion codes. If it repeats after clearing, diagnose it as an active fault rather than continuing to reset it.

Common Symptoms

  • ABS or brake-related warning may be present
  • Brake switch status may not be recognized correctly

Likely Causes

  • Brake switch calibration not completed
  • Brake switch calibration lost after service or power interruption
  • Brake switch or related brake signal problem

Quick Diagnostic Checks

Check first
  1. 1Scan for companion codes and record freeze-frame data (if available).
  2. 2Inspect connectors, harness rub points, and pins for corrosion.
  3. 3Check for other active faults that may be upstream causes (communications, sensors, air/fuel issues).
  4. 4After repair, clear codes and confirm the fault stays inactive after a drive cycle.

Common Fixes

  • Charge the truck air system fully before calibration
  • With key on, press the brake pedal firmly and hold for about five seconds, then release
  • Recheck the fault and inspect the brake switch system if calibration does not complete
Full Technical Guide ↓Share This Fault
Full technical sections↓
FitmentsMeaningHow it worksImagesDetailed guideOEM/Engine notesLocation hintScan tool checksStep-by-step diagnosticDecision guideMisdiagnosisDerate/inducementChecklistToolsPreventionCommunity discussionsCommunity videosCommunity notesShare

What does SPN 1067 FMI 7 mean?

Back to top ↑

When SPN 1067 FMI 7 sets, the ECM is indicating a fault condition involving the component or system named in the code.

OEM definitions and thresholds can vary, so confirm the exact meaning with service information or a capable diagnostic tool.

Treat repeat faults as ACTIVE and diagnose using live data, wiring checks, and basic inspections before replacing parts.

How this system works (why SPN 1067 FMI 7 happens)

Back to top ↑

Most modern fault logic is based on expected versus actual sensor readings, timing windows, circuit checks, and plausibility tests.

A stored code can come from a temporary event, while a repeatable active code gives you a much better diagnostic target.

The goal is to identify whether the failure is electrical, mechanical, sensor-related, or caused by another upstream fault before replacing components.

Detailed guide for SPN 1067 FMI 7

Back to top ↑

What SPN 1067 FMI 7 means

SPN 1067 FMI 7 is documented by Volvo Premium Tech Tool for Bendix systems as a brake switch calibration fault.

The code indicates that the brake switch or brake signal has not been calibrated correctly.

What to check first

Make sure the truck air system is fully charged.

With the ignition switched on, wait a few seconds. Press the brake pedal firmly and hold it for approximately five seconds, then release the pedal.

This procedure allows the Bendix system to learn or calibrate the brake switch signal on applicable vehicles.

If the fault remains

If SPN 1067 FMI 7 remains active after calibration, inspect the brake switch, wiring, connectors and related brake signal inputs.

Check for other ABS or brake-system faults that could prevent calibration from completing.

Important

This interpretation is specifically documented for Bendix-equipped Volvo/Mack applications. Other systems may use different diagnostic logic, so verify the brake-system manufacturer before applying the procedure.

Location hint for SPN 1067 FMI 7

Back to top ↑

Component location varies by OEM and chassis. Use your engine’s service manual to confirm the sensor/valve location before replacing parts.

Tip: Inspect connectors and harness routing before replacing parts.

Scan tool checks for SPN 1067 FMI 7

Back to top ↑
  • Check status: ACTIVE vs INACTIVE / stored and review freeze-frame data when available.
  • Record companion codes and diagnose the earliest or most upstream fault first.
  • Compare live sensor values with expected operating conditions and inspect wiring and connectors.
  • Clear and re-test under similar conditions only after completing the initial inspection.

If your tool can’t run actuator tests, you can still diagnose a lot with careful inspection + repeatability testing.

Step-by-step diagnostic for SPN 1067 FMI 7

Back to top ↑
  1. Visual inspection (fast wins). Harness routing, connector pins, hoses/lines (if applicable), and obvious damage.
  2. Check fluid sanity. Not applicable unless your fault is fluid-related. Focus on inspections + repeatability.
  3. Confirm the fault is ACTIVE. Stored-only faults can be old events.
  4. Review live data and circuit values. Use OEM diagnostic software (examples: Cummins INSITE, Detroit DDDL, PACCAR DAVIE4) or a capable heavy-duty scan tool to review the affected signal, commanded/actual values when applicable, and related sensor data.
  5. Verify after repair. Clear codes, road test, confirm it stays inactive.

Decision guide (fast path) for SPN 1067 FMI 7

Back to top ↑
  • If the fault is STORED only → inspect, clear, and monitor. If it returns, treat it as active.
  • If ACTIVE → inspect the named component, connector, harness, supply/ground, and live-data plausibility.
  • If multiple codes are present → diagnose the earliest or most upstream code first.

Common misdiagnosis mistakes for SPN 1067 FMI 7

Back to top ↑
  • Replacing sensors or components without checking wiring, grounds, connector fitment, and companion codes.
  • Clearing the fault repeatedly without confirming whether it is ACTIVE and repeatable.
  • Missing an upstream fault that is causing the displayed code as a secondary symptom.

Will SPN 1067 FMI 7 cause derate or inducement?

Back to top ↑

This fault may not require immediate shutdown, but repeated or active faults should still be diagnosed.

Exact behavior depends on ECM calibration and which companion faults are active.

“Do this first” checklist for SPN 1067 FMI 7

Back to top ↑
  • Scan for companion codes and record freeze-frame data (if available).
  • Inspect connectors, harness rub points, and pins for corrosion.
  • Check for other active faults that may be upstream causes (communications, sensors, air/fuel issues).
  • After repair, clear codes and confirm the fault stays inactive after a drive cycle.

Tools needed to diagnose SPN 1067 FMI 7

Back to top ↑
  • Basic hand tools + good lighting for inspection
  • Multimeter for connector/power/ground checks (if wiring suspected)
  • OEM diagnostic software (examples: Cummins INSITE, Detroit DDDL, PACCAR DAVIE4) (or equivalent scan tool) for live data and supported diagnostic tests

Prevention tips to avoid repeat SPN 1067 FMI 7

Back to top ↑
  • Fix small wiring/connector issues early before they become repeat faults.
  • During service, inspect harness routing and clamp points near heat/vibration.
  • Don’t ignore intermittent faults. “Erratic” usually gets worse.
